High Pressure Grouting Injection Pump Equipment Slurry Grouting Pump

  • 1
  • 2
  • 3

Brand Name : Sincola

Model Number : GPH-90

Certification : CE,ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 set per month

Delivery Time : 7-10 work days

Packaging Details : wooden case packing

Production name : Cement grouting pump

Feature : High pressure grouting pump

Power type : Electric

Application : Grouting pump

Type : slurry grouting pump

Output : 90L/min

Power(w) : 55kw

Warranty : 1 Year

Contact Now

High Pressure Electric Mortar Injection Pump Cement Grouting Pump

Description

This cement grouting pump is designed according to the market demand of high-pressure grouting pump. This product combined split type pump hydraulic end, motivation to use needle bearing type transmission, low noise, low temperature, ensure 24 hours of continuous operation, suitable for foundation treatment of high-pressure rotary jet grouting, curtain grouting, soil retaining cofferdam anchorage, mine well plugging, the barrel wall, slope and other fields.

High Pressure Grouting Injection Pump Equipment Slurry Grouting Pump

High pressure grouting pump can be used in the following areas
○ Soft foundation treatment, high pressure rotary jet grouting;
○ High-pressure water jet assists in breaking rock and falling coal;
○ Coal mine underground hydraulic props supply liquid;
○ Anchoring hydraulic expansion metal paving rod to pump high pressure water;
○ Underground large pipeline dredging cleaning;
○ Chemical pump;
○ High-pressure water jet, horizontally drilling through holes;
○ Pump for grouting for other purposes;

High Pressure Grouting Injection Pump Equipment Slurry Grouting Pump

Main Technical Parameters

No Main Technical Parameters Unit
Motor Power 55KW 90KW
1 Motor Model GPH90-6 GPH90-4 /
2 Form of Action Horizontal reciprocating single acting plunger type Horizontal reciprocating single acting plunger type /
3 Plungers Quantity 3 3 piece
4 Plunger diameter 50 50 mm
5 Work schedule 100 100 mm
6 Input Rotating speed 390～900 590～1330 r/min
7 Output 32～75 50～110 L/min
8 Working Pressure 36 40 MPa
9 Suction pipe diameter 64 64 mm
10 Discharge pipe diameter 25 25 mm
11 Dimensions 2820×1270×1220 2820×1270×1220 mm
12 Total Weight 3380 3450 Kg

High Pressure Grouting Injection Pump Equipment Slurry Grouting Pump

High Pressure Grouting Injection Pump Equipment Slurry Grouting Pump
